Technical Specifications for 5-Axis Machined Prop: "Golden Hoop Rod"
(Inspired by Black Myth: Wukong)
1. General Information
Component Name: Golden Hoop Rod (金箍棒)
Application: High-precision prop for real-time cinematic rendering and physical stunt replica.
Material: Grade 5 Titanium alloy (Ti-6Al-4V) with carbon fiber composite reinforcement.
Weight: 3.5 kg (Functional prototype).
2. Machine Tool Configuration
- Machine Model: TOSHIBA MACHINE UVM-450(V2) (5-Axis CNC)
- Control System: TOSNUC 8880 CNC with AI-driven toolpath optimization.
3. 5-Axis Machining Parameters
| Parameter | Value |
| Positioning Accuracy | ±0.002 mm |
| Repeatability | ±0.001 mm |
| Spindle Speed Range | 100 – 30,000 RPM (Direct-drive spindle)|
| Tool Diameter Range | 0.3 mm – 20 mm (Diamond-coated tools) |
| Max. Feed Rate | 50 m/min |
| Workpiece Size | 450 mm × 450 mm × 300 mm |
| Tolerance Class | ISO 2768-fH (Ultra-fine machining) |
4. Key Machining Capabilities
- Complex Surface: Multi-axis synchronous machining of mythical runes and micro-scale cloud patterns (Ra ≤ 0.4 μm).
- Deep Cavity Processing: 5-axis tilt/swivel for internal hollow structures (A/C axis: ±120°).
- Dynamic Thermal Control: Real-time temperature compensation for Ti-6Al-4V stability.
5. Post-Processing Workflow
1. Deburring: Non-contact laser deburring for micron-level edges.
2. Surface Coating: Ion-plated gold-titanium nitride (TiAuN) for corrosion resistance.
3. Motion Integration: Embedded inertial measurement units (IMUs) for VR/AR interaction.
6. Quality Validation
- 3D Scanning: Artec Eva 3D scan alignment (accuracy: 0.05 mm).
- Fatigue Test: 1,000+ cyclic load simulations (matching in-game combat dynamics).
Notes
- This is a fictional technical case for demonstrating the UVM-450(V2) modiai capabilities, adapted to *Black Myth: Wukong*'s artistic requirements.
Actual TOSHIBA machine parameters may vary. Consult official manuals for precise specifications.
